Digital Thermometers / Transmitters DPT420V2
Application:
DPT420V2 is designed to measure temperature by standard Pt100 (Pt500, Pt1000) sensors and digitally displays the temperature in °C (or °F). The resolution is 0.1°. The range of the thermometer is proportional to an output of 4-20mA with two-wire connection. The unit remembers this range separately by ° C and by ° F.
The digital transmitter is suitable for use in the food, chemical, pharmaceutical and other industries.
Specifications:
| Case: | stainless steel, Ф100 or Ф80 mm |
| Ingress Protection (IP) Rating: | IP65 |
| Stem Material: | 304 stainless steel* |
| Display: | 4 digits LCD, 11 mm digits height |
| Input: | Pt100 (DIN IEC 751, a=1.385), 3-wire connection |
| Range: | On request in the range of -50 to 600 °С. |
| Analog output: | 4-20 mA, 2-wire connection, loop powered |
| Accuracy: | 0.25 % F.S. |
| RTD probe Accuracy: | 0.5 % F.S. |
| Connection between the sensor and the thermometer: | Ordinary or armoured 2 or 3-wire cable |
| Cable length: | Up to 200-250 m with additional error <0.5% |
| Ambient conditions: | -20..+50 °С |
* On request, the parameters listed in the table can be changed.
